Vectors, Plainly, part 5: RAG end to end, GraphRAG, and graphs beside vectors

Part 5 of 6 in Vectors, Plainly. Earlier: part 1, what a vector database does; part 2, inside the index; part 3, multi-tenancy; part 4, retrieval quality.

Retrieval-augmented generation (RAG) is the reason most teams meet a vector database at all. It is worth seeing the whole loop once, because RAG is an architecture pattern, not a product, and the vector database is exactly one of its boxes. When “RAG isn’t working”, the fault is usually in one of the other boxes.

The loop

The term comes from Lewis et al. (2020), who combined “pre-trained parametric and non-parametric memory”: a language model, plus “a dense vector index of Wikipedia, accessed with a pre-trained neural retriever”. Today’s systems keep that shape.

Ingestion runs offline and whenever sources change: fetch documents, parse them (PDF and HTML extraction is where many projects quietly lose tables and headings), chunk them, embed each chunk, and upsert vectors with the chunk text and metadata. Query runs on every request: embed the question with the same model, search with the tenant and other filters, rerank the shortlist, assemble a prompt with the best chunks and their sources, and let the language model answer with citations.

The vector database does the “search with filters” box, and nothing else. Parsing, chunking, the embedding model, the reranker, the prompt and the generator are separate, swappable components, and each can sink the result.

The variants worth knowing

Variant	How it works	Trade-off against naive RAG
Naive (single-shot)	Embed the question, take the top k, put them in the prompt, generate	Cheapest; weak on multi-part or ambiguous questions
Hybrid	Dense and keyword search, fused (part 2)	Recovers IDs, names and codes; one more search per query
Iterative, multi-hop	Retrieve, let the model decide it needs more, reformulate, retrieve again	Handles compositional questions; more latency and model calls
Agentic	An agent chooses whether and where to retrieve (vector search, SQL, web) and combines tools	Most flexible and most expensive; needs limits on runaway loops
HyDE	The model drafts a hypothetical answer; that is embedded and searched instead of the question	Bridges question wording and answer wording; one extra model call first
Self-RAG, corrective RAG	The system judges its retrieved context and re-retrieves or abstains	Fewer answers built on bad context; adds a judgement step with its own errors
GraphRAG	Vector search plus traversal of an extracted knowledge graph	Strong on relationship questions; costly to build and keep current
Long context, no retrieval	Put the whole corpus, or a big slice, into the model’s context window	No retrieval misses, but cost grows with every token, and long-context recall degrades

A few of these come with papers worth reading. HyDE (Gao et al., 2022) reported that embedding a generated hypothetical document “significantly outperforms” the unsupervised dense retriever Contriever. Self-RAG (Asai et al., 2023) trains a model to decide when to retrieve and to critique what it retrieved. Corrective RAG (Yan et al., 2024) adds “a lightweight retrieval evaluator” that grades the retrieved documents before generation.

The long-context row deserves its own warning. Liu et al. (2023) found that models do best when the relevant information sits at the beginning or end of the input and “significantly degrade” when it sits in the middle. A bigger window is a complement to retrieval, not a replacement, once a corpus outgrows a single prompt.

Ranking and re-ranking are two different jobs

Ranking is the first pass. The index orders candidates by vector distance, or by a fused dense and keyword score, computed for each document independently of the query. That independence is what makes it fast: document vectors are computed once, at ingestion. Sentence-BERT quantified the difference on the pair-finding task: about 65 hours when a BERT model reads every pair of 10,000 sentences together, about 5 seconds with independently computed embeddings.

Re-ranking is a deliberately expensive second pass over the shortlist only. A cross-encoder reads the query and one candidate together and outputs a relevance score, so it sees how the words of the two interact, which a pair of separate vectors cannot capture.

Between the two sits late interaction. ColBERT (Khattab and Zaharia, 2020) keeps one vector per token instead of one per document and matches token against token at query time. Its authors report it runs “two orders-of-magnitude faster” than a BERT cross-encoder with “four orders-of-magnitude fewer FLOPs per query”, at the price of storing far more vectors.

The evidence for reranking is consistent. BEIR found that reranking and late-interaction models achieved “the best zero-shot performances” on average, “however, at high computational costs”. Commercial rerankers keep moving: Cohere’s current generation is Rerank v4.0, in “pro” and “fast” versions. Open cross-encoders exist in several sizes, and a language model can serve as a reranker when volume is low.

The working rule: cast a wide net cheaply (a first pass of 50 to 100 candidates), then spend the expensive model narrowing it to the 3 to 10 chunks the prompt will carry. If you add one thing to a naive RAG system, make it this.

Where the time goes

A well-tuned vector search is rarely the slow part of a RAG request. Generation usually is: the language model reads the assembled prompt and writes the answer, and that cost grows with both. So optimise retrieval for quality first, measured as in part 4, and optimise generation for latency: keep the retrieved context to what is relevant, stream the response, cache repeated prompt prefixes, and send simple questions to smaller models. Part 6 breaks the pipeline down by hardware.

GraphRAG: when the question is about relationships

Plain RAG retrieves passages that sound like the question. It struggles when the answer requires walking relationships: “which vendors used by our EU subsidiaries had a security incident this year?” No single passage sounds like that question. The answer is a path: subsidiary, to vendor, to incident.

GraphRAG adds a knowledge graph of entities and relationships extracted from the same corpus, so retrieval can follow edges as well as distances.

Microsoft’s version, described in Edge et al. (2024), popularised the pattern. Per the project docs, indexing slices the corpus into text units, uses a language model to “extract all entities, relationships, and key claims”, clusters the graph hierarchically with the Leiden algorithm, and generates summaries of each community “from the bottom-up”. Queries then run in several modes: global search answers broad questions about the whole corpus from community summaries; local search starts from entities in the question and expands to their neighbours; DRIFT search mixes the two; and basic search is plain vector retrieval.

The cost is in the indexing. The project README warns that “GraphRAG indexing can be an expensive operation” and advises starting small: you are running a language model over the entire corpus, and keeping a second store in sync with the first. Microsoft Research’s follow-up, LazyGraphRAG, defers most of that work to query time and reports indexing costs “identical to vector RAG and 0.1% of the costs of full GraphRAG”.

GraphRAG earns its keep on relationship-heavy, multi-hop questions and on “what are the main themes across everything” questions. For finding the paragraph that answers a direct question, plain hybrid RAG with reranking is cheaper and usually as good.

Three different things called “graph”

“Graph” appears around vector databases in three unrelated senses, and conflating them causes real confusion.

1. The index is a graph. HNSW (part 2) is a proximity graph. Its edges mean “these two vectors are close” and nothing more. Every HNSW-based vector database “has a graph” in this sense.
2. A knowledge graph beside it. GraphRAG’s graph: entities and relationships extracted from documents, stored in a graph database, and traversed to answer relational questions. Its edges are facts.
3. One engine for both. Some databases store vectors and graph edges together, so a single query can combine “similar to” with “connected to”: graph databases that added vector indexes, and multi-model databases. The payoff is one query and one system; the cost is that each half is usually less mature than a specialist.

For most teams the pragmatic default is to compose: a vector database for similarity, a graph database added only once real multi-hop questions appear, joined in the application or orchestration layer. A single engine makes sense when running two systems costs more than the maturity you give up.

Where RAG specifically is the right shape

• Internal knowledge assistants over policies, wikis and tickets that change too often to train into a model.
• Support copilots grounded in product docs and resolved tickets, citing their sources.
• Legal and compliance research, where answers must quote the exact clause they rest on.
• Code assistants over a private codebase, retrieving the files that matter instead of relying on what the model saw in training.
• Anything after the model’s knowledge cutoff, refreshed by re-indexing instead of retraining.
• Personal assistants over one user’s data (mail, notes, documents), where the corpus is unique per user and could never live in model weights. Part 3’s per-tenant isolation applies here with full force.

---

Next: part 6 of 6, “Production”: sharding and freshness, memory and disk-based indexes, where a GPU is worth it, security and compliance, and where to go next. It publishes tomorrow, 3 October.
