Turn perf samples into a CPU flame graph

perf report gives you a long call tree. It is accurate and hard to scan. A flame graph puts the same samples into one picture, so the expensive code paths stand out by size. Brendan Gregg’s flame graph page says he created the visualization while working on a MySQL performance issue, and released it in December 2011.

This guide walks the classic pipeline: record with perf, fold the stacks, render the SVG, and then read it correctly. The most common mistake comes at the end: reading the x-axis as time.

Record stack samples with perf

The FlameGraph repository gives this command to “capture 60 seconds of 99 Hertz stack samples” across the whole system:

sudo perf record -F 99 -a -g -- sleep 60

To profile one process, swap -a for -p:

sudo perf record -F 99 -p 181 -g -- sleep 60

What each flag does, per the perf-record manual page:

• -F sets the sampling frequency. The perf wiki tutorial says the default is 1000 Hz.
• -a collects from all CPUs.
• -p attaches to an existing process ID.
• -g “enables call-graph (stack chain/backtrace) recording for both kernel space and user space.” Without it you get only the function that was running, with no ancestry, and the flame graph collapses into a flat row.
• sleep 60 sets the duration. perf records until the command exits.

The samples land in perf.data in the current directory.

Clear the permission error first

As a normal user, perf record may refuse to run. The perf wiki explains that /proc/sys/kernel/perf_event_paranoid controls what unprivileged users can do. Level 2 allows “only user-space profiling (no kernel events)”, and level 3 disallows all unprivileged profiling. The wiki shows how to lower it:

sudo sysctl -w kernel.perf_event_paranoid=1

This setting applies to every user on the machine. On a shared host, running perf with sudo is the narrower choice.

Fold the stacks into one line each

Clone the scripts, export the samples as text, and fold them:

git clone https://github.com/brendangregg/FlameGraph
sudo perf script > out.perf
./FlameGraph/stackcollapse-perf.pl out.perf > out.folded

The repository describes the stackcollapse scripts as a way to “fold stack samples into single lines.” Each line is one unique stack, frames joined by semicolons from root to leaf, followed by the number of samples. A made-up example:

myapp;main;handle_request;parse_json 412
myapp;main;handle_request;write_log 37

The folded file is plain text, so you can check it before you render. If grep handle_request out.folded returns nothing, the function never showed up in a sample.

Render the SVG

./FlameGraph/flamegraph.pl --title "api CPU, 60s" out.folded > cpu.svg

Open cpu.svg in a browser. The README lists --title and --width (default 1200), plus --minwidth to omit very small functions. The perf wiki also notes that perf can produce a flame graph itself with perf script report flamegraph.

Read width as time spent

Gregg’s page defines the axes:

• “The x-axis shows the stack profile population, sorted alphabetically (it is not the passage of time).”
• The y-axis is stack depth, counting from zero at the bottom.
• “The wider a frame is is, the more often it was present in the stacks.”
• The top edge shows what was on-CPU, and the boxes below it are its ancestry.
• The original colors are random and only separate neighbouring frames.

So a box that spans 40% of the width appeared in 40% of the samples. With a steady sampling rate, that is roughly 40% of the sampled CPU time. Two boxes side by side tell you nothing about order. parse_json sits left of write_log in the example because “p” sorts before “w”.

Read it in two passes:

1. Look along the top edge for wide plateaus. Those functions were running on the CPU themselves.
2. Look for wide boxes lower down with many thin children. Their cost is spread across callees, and the fix is often in the caller.

If you need the time order, ask for a flame chart instead. The README describes --flamechart as “sort by time, do not merge stacks”.

Fix broken or shallow stacks

Stacks that stop after one or two frames usually mean the unwinder lost track. The perf-record manual page says the default user-space method is fp (frame pointers), and that on binaries built with -fomit-frame-pointer, “using the fp method will produce bogus call graphs.” It names two alternatives:

• --call-graph dwarf, for perf builds linked to libunwind or libdw.
• --call-graph lbr, which “doesn’t require any compiler options” but only works on newer Intel CPUs such as Haswell.

Where this advice stops applying

• Waiting time. A CPU flame graph shows on-CPU stacks. A request that is slow because it waits on a lock, a disk or the network can look small here.
• Runtimes with their own stacks. Gregg’s page notes that Java needs -XX:+PreserveFramePointer for full stacks, and that for Python “basic frame pointer-based stack walking only identifies interpreter frames.” For Python code, a runtime-aware profiler such as py-spy gives readable function names.
• Short events. Sampling at 99 Hz catches where time accumulates. A function that runs rarely and briefly may never appear.
