Link every alert to its runbook with a Prometheus annotation

An alert called ModelServerDown at 3 a.m. tells the person on call that something broke. It does not tell them what to check first. A Prometheus alerting rule can carry that pointer with it: an annotation holding the runbook’s address travels with the alert into the notification.

This guide follows the Prometheus alerting rules documentation and the Alertmanager notification template reference.

Labels and annotations hold different things

The alerting rules page describes two clauses. The labels clause “allows specifying a set of additional labels to be attached to the alert.” The annotations clause “specifies a set of informational labels that can be used to store longer additional information such as alert descriptions or runbook links.” Keep routing data such as severity in labels. Keep text for humans, including the runbook link, in annotations.

runbook_url is a convention

Prometheus defines no special runbook_url field. Its documentation only speaks of “runbook links” in general, so any annotation key works. Community rule sets use the name runbook_url. The kubernetes-mixin alerts published on monitoring.mixins.dev attach summary, description and runbook_url annotations to rules such as KubePodCrashLooping. Using the same key keeps your rules consistent with rule sets you may import from there.

A rule with summary, description and runbook

groups:
- name: model-serving
  rules:
  - alert: ModelServerDown
    expr: up{job="model-server"} == 0
    for: 5m
    labels:
      severity: page
    annotations:
      summary: "Model server {{ $labels.instance }} is down"
      description: "Scrapes of {{ $labels.instance }} have failed for 5 minutes."
      runbook_url: "https://runbooks.example.com/model-serving/model-server-down"

The documentation explains the templating: “The $labels variable holds the label key/value pairs of an alert instance”, and $value holds the evaluated value. The summary is a short line that fits a notification title. The description adds detail for the specific instance. The runbook_url points at one page per alert.

Annotations accept templates, so you could build the URL from labels. A literal link per rule is easier to review and to check.

Make the notification show the link

One failure to watch for is a link that is set on the rule but missing from the notification. The rule carries the annotation, yet the chat message has no link. Alertmanager builds each message from the receiver’s templates, and a template that never references the annotation never shows it.

The notification reference lists two places to read annotations. CommonAnnotations is the “Set of common annotations to all of the alerts” in a group. Each entry in Alerts has its own Annotations. The notification template examples show both styles.

Prefer ranging over Alerts. When one notification groups alerts that have different runbooks, no single runbook_url is common to all of them, so it is left out of CommonAnnotations and the link disappears from the message. Ranging prints each alert’s own link:

receivers:
- name: 'oncall-slack'
  slack_configs:
  - channel: '#oncall'
    title: "{{ range .Alerts }}{{ .Annotations.summary }}\n{{ end }}"
    text: "{{ range .Alerts }}{{ .Annotations.description }}\nRunbook: {{ .Annotations.runbook_url }}\n{{ end }}"

This assumes your Slack webhook is configured as usual. Other receivers have their own fields; check each one’s configuration to see where the link should go.

Test that the annotation stays

A rename or a deleted line can drop the runbook link without anyone noticing. Prometheus rule unit tests catch it. The exp_annotations map holds the expected alert’s expanded annotations. Its labels belong in the separate exp_labels map.

rule_files:
- alerts.yml
evaluation_interval: 1m
tests:
- interval: 1m
  input_series:
  - series: 'up{job="model-server", instance="model-a:8080"}'
    values: '0+0x10'
  alert_rule_test:
  - eval_time: 10m
    alertname: ModelServerDown
    exp_alerts:
    - exp_labels:
        severity: page
        job: model-server
        instance: model-a:8080
      exp_annotations:
        summary: "Model server model-a:8080 is down"
        description: "Scrapes of model-a:8080 have failed for 5 minutes."
        runbook_url: "https://runbooks.example.com/model-serving/model-server-down"

Run it with promtool test rules alerts_test.yml. The documentation does not say whether exp_annotations may list a subset of the annotations, so list all of them. A rule that loses its link then fails in CI.

A dead link is worse than none

Imported rule sets show the risk. In a kube-prometheus issue, a user reported that every alert’s runbook_url pointed at the kubernetes-mixin runbook file and wrote that “runbook_url shouldn’t point to non-existent runbooks.” A Helm charts issue about the old prometheus-operator chart said that “the default runbook_url points to an example repository” and asked for a configurable base path.

When you import alerts, point their links at runbooks you maintain, or confirm the upstream pages exist. The prometheus-operator project runs a runbook site whose stated goal is a “meaningful runbook for every alert in kube-prometheus project”. For your own rules, a CI step that requests every runbook_url and fails on an error status catches broken links before a page does.

Where this stops applying

The annotation is only a pointer. It helps when the runbook is current and reachable from the device the person on call uses; a page behind a VPN may not open on a phone. Large alert groups also produce long messages when you range over every alert, so tune Alertmanager grouping alongside the template.
