Big Pineapple DNS cache: five Rust layout moves reclaim ~100 TB (Cloudflare)

Sebastiaan Neuteboom’s Cloudflare Blog post (2026-08-27) is a Rust-in-production memory-layout case study on Big Pineapple—the platform behind 1.1.1.1, Gateway DNS, DNS Firewall, AS112, and other Cloudflare DNS services—not a product launch or Birthday-week feature wave (Cloudflare Blog).

Cloudflare says Big Pineapple holds over 250 billion DNS cache entries at a time. Five successive changes to how entries sit in memory are the spine of the post.

Five layout moves

1. Vec / String → Box<[T]> / Box<str>. Once an entry is stored, unused capacity is waste. Replacing growable buffers with exact-size boxes drops the three-word capacity header and the reserved tail (Cloudflare Blog).

2. Merged answer / authority / additional + u16 offsets. Three separate lists become one contiguous list with two u16 section offsets—enough for DNS record counts per section—instead of separate pointers and lengths (Cloudflare Blog).

3. Owner as Option<Box<Name>>. When a record’s owner matches the queried name, store None and restore it from the cache key at read time; only divergent owners (for example behind a CNAME) keep a heap name. Wire-format name compression (RFC 1035) is the on-the-wire cousin; the cache still prefers full names when owners differ to keep lookups cheap (Cloudflare Blog).

4. Boxed large RecordData enum variants (interim). Rust enums are sized to the largest variant. Boxing rare large variants (such as NAPTR) shrinks the common A / AAAA path, at the cost of extra allocations and weaker locality—an intentional stepping stone (Cloudflare Blog).

5. Wire-format record buffer as Box<[u8]>. Record data becomes a single buffer of 2-byte length prefixes plus raw bytes, built via a reusable scratchspace on insert. Contiguous bytes improve locality; many types copy straight into responses. This supersedes the boxed-enum interim on the hot path (Cloudflare Blog).

Vendor metrics (Cloudflare only)

Treat every figure as a Cloudflare vendor claim from benches and production RSS—not an independent newsroom measurement (Cloudflare Blog):

Claim (CF)	Figure
Per-entry net footprint	953 → 420 bytes (−56%)
Fleet working-set	~100 TB lower
Insert throughput	+43% (625k → 893k entries/s)
Lookup latency	−19% (828 → 670 ns)
Production RSS	p99 9.3 → 5.3 GB; p90 6.5 → 3.8 GB

CF’s benches used a custom allocator wrapping Rust’s System allocator and a synthetic mix (~56% A / 25% AAAA / 19% TXT). Process RSS also depends on traffic mix, occupancy, allocator state, and non-cache memory, as the post states.

Rollout window

Production rollout started 2026-05-18 and finished across services 2026-07-06, in stepped releases. Restarts began with empty caches; steady-state plateaus matter more than the first dips (Cloudflare Blog).

Who should care

Rust systems teams packing hot-path structs at fleet scale—exact-size boxes, packed sections, optional owners, enum sizing, then contiguous wire bytes—should read Neuteboom’s primary post. Keep the frame on layout engineering; leave Birthday product desks and inventing competitor-resolver comparisons elsewhere.
