A swapped-out process looks small in a memory list

When a machine runs short of memory, the first move is usually a process list sorted by memory. On a machine that has started swapping, that list can point at the wrong process.

What “resident” leaves out

The column most tools sort by is resident memory, often labelled RES or RSS. It counts the pages a process has in physical memory right now. The proc_pid_status(5) manual page calls the field VmRSS, the “Resident set size”, and says it is the sum of RssAnon, RssFile and RssShmem.

When the kernel pushes a process’s pages out to swap, those pages stop being resident. The process still owns them, and it will need them back, but its resident figure drops. A large idle process can shrink to almost nothing in the list while its real footprint has only moved.

I measured this on a machine during a memory shortage. One long-running service showed 0.1 GB resident. The same service had 2.6 GB in swap. Sorted by resident memory, it sat far down the list, below processes a tenth of its true size.

Where the swapped part is recorded

The same status file carries a second field. The manual page describes VmSwap as the “Swapped-out virtual memory size by anonymous private pages”, and adds that “shmem swap usage is not included”. It has been there since Linux 2.6.34.

Two cautions from the same page. Shared memory that was swapped out is missing from VmSwap, so the figure is a floor. And the page marks VmRSS and VmSwap alike with “This value is inaccurate”, which is a reason to read them as estimates, good for ranking and poor for accounting.

Ranking by both

This loop prints the ten largest processes by resident memory plus swap, in kilobytes: total, resident, swap, name.

for f in /proc/[0-9]*/status; do
  awk '/^Name:/{n=$2} /^VmRSS:/{r=$2} /^VmSwap:/{s=$2}
       END{if (r+s > 0) printf "%d\t%d\t%d\t%s\n", r+s, r, s, n}' "$f" 2>/dev/null
done | sort -rn | head

Kernel threads have no memory fields and drop out through the r+s > 0 test. A process that exits between the listing and the read produces an error, which the redirect hides.

Many tools can show the same thing if asked. In top, a SWAP column can be added to the field list. The point is to ask, because the default view sorts by the resident column.

Which list answers which question

The two rankings are both useful, for different questions.

• Resident only shows what is occupying physical memory at this moment. It is the right list for “what is the machine busy holding in RAM”.
• Resident plus swap shows who owns the memory overall. It is the right list for “what should I restart, shrink or move to get the machine healthy”.

A monitoring tool that records only the top processes by CPU, or only by resident memory, will lose the swapped-out holder from its history at exactly the time someone needs it. If you keep history, keep the swap figure per process next to the resident one.

Lantern note: on a swapping machine, the smallest-looking process may be the largest one. Add the swap column before you decide what to stop.
