A CPU percentage needs two readings

A process list shows a CPU percentage next to each process, and it looks like a reading, the way a thermometer gives a temperature. The kernel keeps no such number. It keeps a running total of CPU time used, and every percentage is arithmetic done on two readings of that total.

What the kernel records

The proc_pid_stat(5) manual page lists the fields of /proc/<pid>/stat. Field 14, utime, is the “Amount of time that this process has been scheduled in user mode, measured in clock ticks”. Field 15, stime, is the same for kernel mode. To turn ticks into seconds, the page says to divide by sysconf(_SC_CLK_TCK).

Both are running totals of time used. They only go up.

Two tools, two intervals

A percentage needs an interval, and tools choose different ones.

The ps(1) manual page defines its %cpu column as “the CPU time used divided by the time the process has been running”. That is an average over the whole life of the process. A service that worked hard for one minute and then idled for a day shows almost zero.

The top(1) manual page defines %CPU as “The task’s share of the elapsed CPU time since the last screen update”. That is the recent interval, a few seconds long. The same page notes that a multi-threaded process can show “amounts greater than 100%”.

So ps and top can report very different figures for one process at one moment, and both are computing what their manual says.

Doing it by hand

This reads the counter twice, five seconds apart, and prints the percentage of one CPU the process used in between:

pid=1234
hz=$(getconf CLK_TCK)
ticks() { sed 's/.*) //' "/proc/$1/stat" | awk '{print $12 + $13}'; }
a=$(ticks "$pid"); sleep 5; b=$(ticks "$pid")
echo "$(( (b - a) * 100 / hz / 5 ))%"

The sed step removes everything up to the closing parenthesis of the process name. A name can contain spaces, which would shift every field after it. Once the name is gone, fields 14 and 15 are the 12th and 13th.

How a tool gets it wrong

Three mistakes follow from the arithmetic.

1. The first reading has no answer. With one sample there is no difference to compute. A tool that shows a value on its first pass has made one up, usually zero.
2. The wrong interval. Divide a few seconds of work by the time since boot and every process rounds to zero.
3. A process seen once. Short-lived processes that start and finish between two readings never get a percentage at all, however much CPU they used.

I met the second one in a monitoring tool. Its history showed 0.0 % for almost every process for days, while ps showed several of them above 90 %. The tool was dividing by far too long an interval. Nobody had noticed, because a column of small numbers looks plausible on a quiet machine.

The check that caught it is cheap: pick one busy process, compute its share from the counters as above, and compare with what the tool shows for the same seconds. After the fix, six processes agreed with the counters to within 0.3 points.

Lantern note: a percentage is a subtraction and a division. Ask what was subtracted and what it was divided by.
